Simple, Integrated Design
Engineered from the ground up as part of the ShoreStation Lift. The “big
wheel”, remote drive motor, and motor mounts have all been eliminated,
for simple,trouble-free operation. The stylish, corrosion-free case gives
the unit a clean, finished appearance.
Speed Matters
This new system out-performs after-market direct drives and, in speed
tests it even came close to matching our top-of-the-line hydraulic lifts. (See
back for details.)
Powerful Control at Your Fingertips
State-of-the-art electronic control system offers the ultimate in
push-button convenience. Comes standard with 2 remote transmitters, or use
the convenient touch-pad controls on the winch case.
Maximum Safety & Security
User-programmable security codes to prevent theft.
Adjustable upper limit switch stops the platform at any desired height.
Back-wind sensor prevents damage to lift.
Choose Your Power Source
Available in three different power configurations: 120 volt AC,
12 volt DC, or upgrade to the 24 volt DC for
maximum speed. The adjustable motor speed can be fine-tuned to fit your
power source. Solar charging accessory also available!
|
| Model |
Load
Capacity |
Max.
Beam |
Material |
|
SSV40108EDCDW
|
4000
lb. |
108
" |
N/A |
|
SSV15100EAC
|
1500
lb. |
100
" |
N/A |
|
SSV15100EACDW
|
1500
lb. |
100
" |
N/A |
|
SSV15100EDC
|
1500
lb. |
100
" |
N/A |
|
SSV15100EDCDW
|
1500
lb. |
100
" |
N/A |
|
SSV20100EACDW
|
2000
lb. |
100
" |
N/A |
|
SSV20100EDC
|
2000
lb. |
100
" |
N/A |
|
SSV20100EDCDW
|
2000
lb. |
100
" |
N/A |
|
SSV30108EAC
|
3000
lb. |
108
" |
N/A |
|
SSV30108EACDW
|
3000
lb. |
108
" |
N/A |
|
SSV30108EDC
|
3000
lb. |
108
" |
N/A |
|
SSV30108EDCDW
|
3000
lb. |
108
" |
N/A |
|
SSV30120EAC
|
3000
lb. |
120
" |
N/A |
|
SSV30120EACDW
|
3000
lb. |
120
" |
N/A |
|
SSV30120EDC
|
3000
lb. |
120
" |
N/A |
|
SSV30120EDCDW
|
3000
lb. |
120
" |
N/A |
|
SSV40108EAC
|
4000
lb. |
108
" |
N/A |
|
SSV40108EACDW
|
4000
lb. |
108
" |
N/A |
|
SSV40108EDC
|
4000
lb. |
108
" |
N/A |
|
SSV40120EAC
|
4000
lb. |
120
" |
N/A |
|
SSV40120EACDW
|
4000
lb. |
120
" |
N/A |
|
SSV40120EDC
|
4000
lb. |
120
" |
N/A |
|
SSV40120EDCDW
|
4000
lb. |
120
" |
N/A |
|
SSV15100EACSS
|
1500
lb. |
100
" |
N/A |
|
SSV15100EDCSS
|
1500
lb. |
100
" |
N/A |
|
SSV20100EACSS
|
2000
lb. |
100
" |
N/A |
|
SSV20100EDCSS
|
2000
lb. |
100
" |
N/A |
|
SSV30108EACSS
|
3000
lb. |
108
" |
N/A |
|
SSV30108EDCSS
|
3000
lb. |
108
" |
N/A |
|
SSV30120EACSS
|
3000
lb. |
120
" |
N/A |
|
SSV30120EDCSS
|
3000
lb. |
120
" |
N/A |
|
SSV40108EACSS
|
4000
lb. |
108
" |
N/A |
|
SSV40108EDCSS
|
4000
lb. |
108
" |
N/A |
|
SSV40120EACSS
|
4000
lb. |
120
" |
N/A |
|
SSV40120EDCSS
|
4000
lb. |
120
" |
N/A |
|
SSV60120EDCDW
|
6000
lb. |
120
" |
N/A |
|
|
|
Road
Transport Kit
 SSAA
- Just the ticket for towing your lift to and from the water.
Just add rubber to the wheels provided, attach the kit to the
unit and your lift is roadworthy. The kit includes:
- Two
Spindle/Hub Assemblies - SS#50
- Two
15" Rims - SS#51's
- One
set of attaching Brackets - SS#230A
- One
Tongue Assembly - SS#231A
For
Models from 2000 - 7000 lbs.
|
On
Water Transport Kit
 HA0014
- The On Water Transport kit is designed to assist floating your
hoist over open water to its destination if equipped with an
adequate form of floatation. It adjusts to fit all aluminum
lifts available.
|
Carrying
Handles
 SS#233A
- Carrying Handles make carrying a lift into position just a
little bit easier for you and three friends.
For Models with capacities from 2000 to 6000 lbs.
|
Electric
Drive
 SSDC2,
12V and SSAC2, 110V Electric Drives - With an electric drive,
all it takes is a flip of a lever and throw of a switch before
your lift will be raised safely into storage position.
SSDC2 (12V) runs on rechargeable power from your boat or remote
12V source.
SSAC2 (110V) powers your lift with AC power from the shore. Both
can be manually engaged and disengaged for hand operation.
For Models from 2000 to 6000 lbs.
|
Extension
Legs
 SSKA
- Extension legs are to be used on 2000 lb. to 4000 lb. lifs for
deep water applications.
SSKA-55 - Extension legs for lifts 5000 to 7000 lbs.
|
Front
End Boat Stop
The aluminum boat stop with large foam cushion for extra
protection.
HA1180 - for 1500 to 4000 lb. lifts; HA1242 - for 3000 and 9000
lb. lifts.
|
Centering
Guides
Carpeted
centering guides are especially helpful in rough waters.
HA0011 - For 1500 to 4000 lb. lifts.
HA0012 - For 5000 lb. and 6000 lb. lifts and for the 4000 lb.
and 6000 lb hydraulic lifts.
|
Pontoon
Conversion Kit
 SSPV
- Converts your SSV30108, SSV40108 or SSV40120 lift to a
center-lift pontoon lift. All the necessary hardware provided,
all you do is buy the wood locally.
|
Canopy
 The
vinyl-coated nylon fabric canopy feature the new innovative SpoolSnap
attaching system and a longer valance for added protection.
Canopy is available in a variety of colors. See color
chart.
|
Guides
& Bumpers
 SSHA
and SSN-36 - The SSHA consists of two cradle brackets mounted on
the crossmember that self-align with the boat on them, keeping
it from tilting right or left. The SSN-36 are the white
polystyrene foam uprights that act as bumpers when loading or
launching your boat keeping it centered for a smooth landing or
a clean getaway.
For Models SS36110
|
|
